Product Summary
The MAX9205EAI is a 10-Bit Bus LVDS serializer which transforms 10-bitwide parallel LVCMOS/LVTTL data into a serial highspeed
bus low-voltage differential signaling (LVDS) data stream.
Parametrics
Absolute maximum ratings: (1)VCC to GND: -0.3V to +4.0V; (2)IN_, SYNC1, SYNC2, EN, TCLK_R/F, TCLK, PWRDN to GND: -0.3V to (VCC + 0.3V); (3)OUT+, OUT- to GND: -0.3V to +4.0V; (4)Output Short-Circuit Duration: Continuous; (5)Continuous Power Dissipation (TA = +70℃) 28-Pin SSOP (derate 9.5mW/℃ above +70℃): 762mW; (6)Storage Temperature Range: -65℃ to +150℃; (7)Junction Temperature: +150℃; (8)Operating Temperature Range: -40℃ to +85℃; (9)Lead Temperature (soldering, 10s): +300℃; (10)ESD Protection (Human Body Model, OUT+, OUT-): ±8kV.
Features
Features: (1)Standalone Serializer (vs. SERDES) Ideal for Unidirectional Links; (2)Framing Bits for Deserializer Resync Allow Hot Insertion Without System Interruption; (3)LVDS Serial Output Rated for Point-to-Point and Bus Applications; (4)Wide Reference Clock Input Range: 16MHz to 40MHz; (5)Low 34mA Supply Current; (6)10-Bit Parallel LVCMOS/LVTTL Interface.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
MAX9205EAI |
Maxim Integrated Products |
LVDS Interface IC |
Data Sheet |
Negotiable |
|
|||||||||||||
MAX9205EAI/V+ |
Maxim Integrated Products |
Serializers & Deserializers (Serdes) Interface IC 10-Bit Bus LVDS Serializer |
Data Sheet |
Negotiable |
|
|||||||||||||
MAX9205EAI-T |
Maxim Integrated Products |
LVDS Interface IC |
Data Sheet |
Negotiable |
|
|||||||||||||
MAX9205EAI+ |
Maxim Integrated Products |
Serializers & Deserializers (Serdes) Interface IC 10-Bit Bus LVDS Serializer |
Data Sheet |
|
|
|||||||||||||
MAX9205EAI+T |
Maxim Integrated Products |
Serializers & Deserializers (Serdes) Interface IC 10-Bit Bus LVDS Serializer |
Data Sheet |
|
|
|||||||||||||
MAX9205EAI/V+T |
Maxim Integrated Products |
Serializers & Deserializers (Serdes) Interface IC 10-Bit Bus LVDS Serializer |
Data Sheet |
Negotiable |
|
